Komodo

DS112

Versatile & moderate-output P.A.F. '57 humbucker with unmatched bobbin winding design. Its coils deliver a warm, balanced, and sustain-filled tone, yet with greater dynamics and definition than vintage Alnico 2 models. The neck version is creamy, grainy, and offers beautiful sustain, while the bridge version becomes crystalline and rounded with notes that keep screaming over time with classic distortions. Comes with a 4-conductor shielded wire for multiple wiring options. Proudly made in Florida-BA, this pickup is hand built in our workshop and wax potted for squeal free operation.

  • OUTPUT: Moderate
  • DC RESISTANCE: 8.7K (neck) y 9K (bridge)
  • MAGNET: ALNICO 2 bar
  • RESONANCE PEAK: 2.92KHz (neck) y 2.78KHz (bridge)
  • INDUCTANCE: 4.96 Henries (neck) y 5.39 Henries (bridge)
  • HUM CANCELLING: Yes

DS112-N

6
BAss
7
Mid
7
Treble

DS112-B

6
Bass
7
Mid
7
Treble
  • WINDING: Closed winding method that provides extra sensitivity and sustain compare to any other humbucker pickup.
  • CABLE: 4-conductor shielded
  • COLORS: black, mint yellow/turquoise
  • BASE: shielded CEM1 with easy-connector system.
  • INCLUDED COMPONENTS: Mounting screws, pickup height adjustment springs and wiring diagram.
